Enterprise asset
Digitalize and simplify the asset management within your organization.
The LTB01-S LoRaWAN Solar GPS Asset Tracker bridges the gap with an intelligent dual-positioning system that seamlessly switches between indoor BLE scanning and outdoor GPS tracking. Engineered for enterprise asset management, industrial logistics, and livestock monitoring, this compact device eliminates blind spots entirely. Equipped with solar power capabilities and advanced anti-tamper security, the LTB01-S ensures your critical property remains visible and protected around the clock without the burden of frequent maintenance.
- LoRaWAN standard protocol
- Over 2km (1.24 miles) communication range (open areas)
- GPS positioning
- Built-in accelerometer
- Dual reporting mode
- Anti-tamper alarm
- 2400 mAh battery
- IP65 water and dust resistance
Long Range Transmission
This LoRaWAN-based multiband device supports nearly all frequency bands in global areas. Use the LTB01-G GPS asset tracker to build a scalable asset tracking solution based on the LoRaWAN network, with a communication range of up to 2 km (in open areas).
Accurate Tracking Globally
• GPS Positioning System
• Positioning accuracy: 5m-10m
Periodic or Movement-based
Receive location updates regularly, or when the movement occurs. Always track your assets accurately with this GPS asset tracking device.
Periodic Mode
Customize the report interval to regularly receive the location updates.
Motion Mode
Get instant notifications for stop/move tracking when the accelerometer is triggered.
Ultra Low Power
With a built-in 2400 mAh battery and low power consumption supported by LoRaWAN technology, the LTB01-G GPS tracker enables an extended track-and-trace period.
Theft Prevention
With a switchable anti-tamper design, the LTB01-G tracker ensures all your assets are effectively managed and protected, including the tracker itself.
Problems it solve
-
-
Cold chain
Real-time location updates to ensure perishables arrive on schedule.
-
Warehouse
Instantly locate and check stock.
-
Container
Monitor shipments port-to-port with pinpoint GPS reliability.
-
Shared bicycles
Prevent theft and help optimize the deployment of shared bicycles.
Specifications
| Basic Info. | |
|---|---|
| Shell Material | PC |
| Size | 111mm*65mm*33mm |
| Power Supply | rechargeable lithium battery |
| Battery | 3.7V / 2400mAh(rechargeable) |
| Battery Life Estimates | Once every 6 hours location updates – 180 days Once every 30 minutes location updates – 30 days |
| Operating Temperature | -20℃ ~ 60℃ |
| Operating Humidity | 10% ~ 95% RH, non-condensing |
| Protection | IP65 |
| LoRaWAN Specs. | |
| Operating Frequency | Multiple bands optional: EU868 / US915 / AS923 / KR923 / IN865 etc |
| Communication Protocol | Standard LoRaWAN® protocol |
| Operating Mode | Class A |
| Communication Distance | >2km (1.24 miles) in open area |
| Reporting | 30 minutes (adjustable), immediate reporting when accelerometer is triggered |
| Hardware Specs. | |
| GPS | Positioning accuracy 5m-10m, supports GPS and Beidou dual-mode positioning |
| Sensor | Accelerometer |
| Button | Power on / Reset |
FAQs
Why is the LTB01-G LoRaWAN GPS Tracker not reporting GPS data?
The LTB01-G requires outdoor GPS signal to acquire and report location data. If the reporting interval is too short, such as 60 seconds, the device may not complete GPS acquisition in time. It typically takes about 70 seconds to fix a location, so data may be reported without GPS information. We recommend setting the GPS reporting interval to 120 seconds or longer to ensure reliable location updates.
