Enterprise asset
Digitalize and simplify the asset management within your organization.
The LTB01-G LoRaWAN GPS Asset Tracker is a wireless monitoring device based on the standard LoRaWAN protocol. It features GPS technology and an accelerometer for accurate location and movement tracking. This GPS asset tracking device automatically acquires GPS positioning data during movement and supports data transmission over distances exceeding 2km (1.24 miles). The LTB01-G asset tracker is compact, battery-powered, and has ultra-low power consumption. With its anti-theft design and easy installation, it can be easily deployed in settings such as enterprise asset management, mobile property tracking, livestock monitoring, bulk goods oversight, and shared bicycle systems.
- LoRaWAN standard protocol
- Over 2km (1.24 miles) communication range (open areas)
- GPS positioning
- Built-in accelerometer
- Dual reporting mode
- Anti-tamper alarm
- 2400 mAh battery
- IP65 water and dust resistance
Long Range Transmission
This LoRaWAN-based multiband device supports nearly all frequency bands in global areas. Use the LTB01-G GPS asset tracker to build a scalable asset tracking solution based on the LoRaWAN network, with a communication range of up to 2 km (in open areas).
Accurate Tracking Globally
• GPS Positioning System
• Positioning accuracy: 5m-10m
Periodic or Movement-based
Receive location updates regularly, or when the movement occurs. Always track your assets accurately with this GPS asset tracking device.
Periodic Mode
Customize the report interval to regularly receive the location updates.
Motion Mode
Get instant notifications for stop/move tracking when the accelerometer is triggered.
Ultra Low Power
With a built-in 2400 mAh battery and low power consumption supported by LoRaWAN technology, the LTB01-G GPS tracker enables an extended track-and-trace period.
Theft Prevention
With a switchable anti-tamper design, the LTB01-G tracker ensures all your assets are effectively managed and protected, including the tracker itself.
Problems it solve
-
-
Logistics
Real-time updates on parcel location to enhance customer experience.
-
Warehouse
Instantly locate and check stock.
-
Livestock
Track and monitor livestock for location and movement. Set up a digital geofence.
-
Shared bicycles
Prevent theft and help optimize the deployment of shared bicycles.
Specifications
| Basic Info. | |
|---|---|
| Shell Material | PC |
| Size | 111mm*65mm*33mm |
| Power Supply | Built-in battery |
| Battery | 3.7V / 2400mAh(rechargeable) |
| Service Life | 6 months |
| Operating Temperature | -20℃ ~ 60℃ |
| Operating Humidity | 10% ~ 90% RH, non-condensing |
| Protection | IP65 |
| LoRaWAN Specs. | |
| Operating Frequency | Multiple bands optional: EU868 / US915 / AS923 / KR923 / IN865 etc |
| Communication Protocol | Standard LoRaWAN® protocol |
| Operating Mode | Class A |
| Communication Distance | >2km (1.24 miles) in open area |
| Reporting | 30 minutes (adjustable), immediate reporting when accelerometer is triggered |
| Hardware Specs. | |
| GPS | Positioning accuracy 5m-10m, supports GPS and Beidou dual-mode positioning |
| Sensor | Accelerometer |
| Button | Power on / off, Reset |
